TGL20 Table Top High Speed Refrigerated Centrifuge

Features:
1. Digital display indicates the speed,time,temperature and RCF.
2. Brushless DC motor in great torque, free maintenance,no powder pollution.quick in speed up and down.
3. There are many kinds of rotors for choice.
4. Automatically electric lid lock,super speed,over temperature protection and imbalance protection.
5. The centrifuge body is made of high-quality steel,safe and reliable.

  • TGL20

  • Yingtai

Availability:
Quantity:
Inquire Add to Basket


TGL20 Technical Parameters

Max Speed

21000r/min

Max Volume

6×100ml

Timer

1~99h59min

Dimension

570×620×380mm

Speed Accuracy

±20r/min

Max RCF

30910×g

Noise

≤58dBA

Net Weight

84KG

Power supply

AC 220V, 50HZ 10A

Temperature Range

-20℃~40℃

Temperature Accuracy

±1℃

              Matched Rotors for TGL20

Order no

Rotor

Max Speed(r/min)

Volume(ml)

Max RCF(*g)

G20-1

Fixed Rotor

16000

4×8PCR

15760

G20-2

Fixed Rotor

15000

6×8PCR

21420

G20-3

Fixed Rotor

16000

8×8PCR

17480

G20-4

Fixed Rotor

15000

12×8PCR

22930

G20-5

Fixed Rotor

21000

12×1.5/2ml

30910

G20-6

Fixed Rotor

15000

40×0.5ml

22920

G20-7

Fixed Rotor

17000

24×1.5/2ml

26460

G20-8

Fixed Rotor

13500

30×1.5/2ml

19340

G20-9

Fixed Rotor

13000

48×1.5/2ml

17930

G20-10

Fixed Rotor

16000

16×5ml

22020

G20-11

Fixed Rotor

16000

6×10ml

21500

G20-12

Fixed Rotor

15000

12×10ml

22680

G20-13

Fixed Rotor

16000

12×7ml

21380

G20-14

Fixed Rotor

13000

16×10ml

19490

G20-15

Fixed Rotor

10000

12×15ml

11840

G20-16

Fixed Rotor

13000

8×15ml(falcon)

17790

G20-17

Fixed Rotor

5000

24×15ml

3500

G20-18

Fixed Rotor

15000

8×20ml

22680

G20-19

Fixed Rotor

5000

30×15ml

3830

G20-20

Fixed Rotor

14000

6×30ml

19060

G20-21

Fixed Rotor

13000

6×50ml(falcon)

18840

G20-22

Fixed Rotor

13000

6×50ml(round)

18730

G20-23

Fixed Rotor

13000

4×85ml

18940

G20-24

Fixed Rotor

12000

6×70ml

15570

G20-25

Fixed Rotor

12000

4×100ml

14850

G20-26

Fixed Rotor

12000

6×100ml

16390

G20-27

Fixed Rotor

12000

24 pieces capillary vessel

15800

G20-28

Fixed Rotor

18000

30×0.5ml

26660

G20-29

Swing Rotor

13000

4×5ml

14960

G20-30

Vertical Rotor

16000

16×5ml

16540

G20-31

Vertical Rotor

14000

8×30ml

16450

G20-32

Microplate Rotor

4000

2×3×48（well）

2300
