Features
1.Brushless frequency motor, in great torque, free maintenance, no powder pollution, quick in speed up and down.
2.Imported compressors fluorine free,double cycle cooling, cold and hot alternating easily, free environment pollution and precise in temperature control.
3.Microprocessor control, digital display which indicates the temperature, speed, time, RCF in operation, speed raising and reducing quickly, operate simply. Running parameter can be edited.
4. 10 kinds of program stored in the memory, 10 kinds of accelerating and decelerating speed for your choice.
5. Automatically electric lid lock, over speed, over temperature protection and imbalance protection.
6.High quality steel centrifuge body , stainless steel chamber, built-in stainless steel explosion-proof protect sleeve , 3 tiers protection,safe and reliable.
7. Rotor is connected to spindle by specialized spring taper sleeve, loading simple and quick, no direction
8. With pre-cooling and get the ideal centrifugation result.
TGL16 Technical Parameter：
Max. Speed | 16000rpm |
Max. RCF | 20600×g |
Max. Capacity | 6×100ml |
Time Range | 1~9h59min |
RPM/RCF Convert | Yes |
Noise (dB) | ≤ 58 |
Acc/Dec | 10 Kinds |
Speed Accuracy | ±20r/min |
Temperature Accuracy | ±1℃ |
Voltage(V/Hz) | AC 220V/110V 50HZ/60HZ |
Size (L x W x Hmm) | 610×570×370mm |
Net Weight(Kg) | 82KG |
Certificates | TUV CE,ISO 9001,ISO13485 & Calibration report are available |
Matched Rotor for TGL16
Order No | Rotor | Max speed (rpm) | Max Volume(ml) | Max RCF (g) |
G16-1 | Angle rotor | 14000 | 4×8PCR | 12070 |
G16-2 | Angle rotor | 13000 | 6×8PCR | 16080 |
G16-3 | Angle rotor | 14000 | 8×8PCR | 13390 |
G16-4 | Angle rotor | 13000 | 12×8PCR | 17220 |
G16-5 | Angle Rotor | 15000 | 30×0.5ml | 18510 |
G16-6 | Angle Rotor | 14000 | 40×0.5ml | 19970 |
G16-7 | Angle Rotor | 16000 | 12×1.5/2ml | 17940 |
G16-8 | Angle Rotor | 15000 | 24×1.5/2ml | 20600 |
G16-9 | Angle Rotor | 13500 | 30×1.5/2ml | 19340 |
G16-10 | Angle Rotor | 11000 | 48×1.5/2ml | 12840 |
G16-11 | Angle Rotor | 15000 | 16×5ml | 19350 |
G16-12 | Angle Rotor | 14000 | 12×7ml | 16370 |
G16-13 | Angle Rotor | 14000 | 6×10ml | 16460 |
G16-14 | Angle Rotor | 12000 | 12×10ml | 14510 |
G16-15 | Angle Rotor | 10000 | 12×15ml | 11840 |
G16-16 | Angle Rotor | 5000 | 24×15ml | 3080 |
G16-17 | Angle Rotor | 5000 | 30×15ml | 3830 |
G16-18 | Angle Rotor | 12000 | 8×20ml | 14510 |
G16-19 | Angle Rotor | 12000 | 6×30ml | 14000 |
G16-20 | Angle Rotor | 11000 | 6×50ml | 13480 |
G16-21 | Angle Rotor | 12000 | 6×70ml | 10810 |
G16-22 | Angle Rotor | 8000 | 6×100ml | 7280 |
G16-23 | Angle Rotor | 12000 | 24 pieces capillary vessel | 15800 |
G16-24 | Microplate rotor | 4000 | 2×3×48 Well | 2300 |
