CDL7M Technical Parameter:
| Max. Speed | 7000rpm | Acc/ Dcc | 10 Kinds |
| Max. RCF | 11650xg | Speed Accuracy | ±20r/ min |
| Max. Volume | 6x2400ml(12*500ml blood bag) | Temperature Accuracy | ±1ºC |
| Timer | 1-9h59min | Voltage (V/ HZ) | AC 220V/ 110V 50HZ/60HZ |
| RPM/ RCF Convert | Yes | Size (W × D × Hmm) | 940 × 890 × 1000mm |
| Noise (dB) | ≤ 65 | Net Weight (Kg) | 570KG |
| Temperature Range | -20~40ºC | Certificates | CE, ISO & Calibration report are available |
Matched Rotors for CDL7M
| Oeder Number | Rotor Type | Max. Speed (rpm) | Max. Volume(ml) | Max. RCF |
| No 05603 | Swing Rotor | 4000 | 6x2400ml | 5330 |
| No 05165 | Angle Rotor | 7000 | 6x1000ml | 11650 |
| No 05646 | Swing Rotor | 4200 | 2x6x1000ml | 5680
|
Company overview
Changsha Yingtai Instrument Co.,Ltd has been specialized in manufacturing various centrifuges since 2001, as one of first-class centrifuge manufactures in China, we can make nearly all series of centrifuges. In recent years, we have launched new products, including the freeze dryer, concentrator, autoclave, and tube sealer. After being introduced to the market, they have received positive feedback and gained the trust of our customers.
At Yingtai, we have established an extensive sales and service network, and we also owns oue technical and design department, which enable us to provide quality products and service according to different requirement of customers both for domestic market and overseas market.
We are always adhering to the quality principle. Great efforts are being made to improve quality and services. Our products have exported to over 100 coutries, such as USA, UK, Germany, Spain, Italy, Mexico,Brazil, Turkey, Russia, Indonesia, Singapore, Thailand, Korea, Japan etc.
