Product Introduction
1. Microprocessor precise control, high-torque brushless DC motor drive, high-definition LCD screen with large digital display, clear and bright, quick and easy operation.
2. Built-in steel protective inner liner for reliable safety assurance.
3. Equipped with an electromagnetic door lock and multiple safety features, including overspeed, imbalance, overload, and door cover checks, with an emergency lid-opening mechanism that allows opening the centrifuge lid during power outages.
4. Can store up to 9 user-defined centrifuge programs (including 1 two-step gradient program and 1 three-step gradient program) for commonly used centrifugation protocols, saving time in workflow.
5. Compatible with various rotor specifications, with capacities ranging from 5ml to 50ml, meeting the needs of routine clinical and life science research.
6. 10 adjustable acceleration and deceleration levels to optimize centrifugation results.
7. Smooth airflow guide design maximizes the use of natural convection between hot and cold air, forming an efficient heat dissipation cycle to prevent overheating of samples.
8. Quiet operation with noise levels below 56 dBA, providing a comfortable working environment.
Technical Parameters
Max. Speed | 4000r/min |
Max. Capacity | 24×10ml |
Max. RCF | 2250×g |
Timer | 0~99min59s |
Speed Accuracy | ±10r/min |
Noise | ≤56dBA |
Voltage | 100W |
Power | AC 110~220, 50Hz |
Dimension | 430*330*250mm |
Net Weight | 13kg |
Adapter Rotor
| Order NO. | Rotor Type | Max. Speed (rpm) | Max. Volume(ml) | Max. RCF (xg) |
| No 05180 | Angle Rotor | 4000 | 6x50ml | 2100 |
| No 05174 | Angle Rotor | 4000 | 12x10ml | 2150 |
| No 05177 | Angle Rotor | 4000 | 12x15ml | 2150 |
| No 05198 | Angle Rotor | 4000 | 12x20ml | 2220 |
| No 05175 | Angle Rotor | 4000 | 18x10ml | 2250 |
| No 05176 | Angle Rotor | 4000 | 24x10ml | 2200 |
| No 05179 | Angle Rotor | 4000 | 30x7ml | 2250 |
| No 05001 | Angle Rotor | 4000 | 30x5ml | 2060 |
| No 05242 | Swing Rotor | 4000 | 6x10ml | 2214 |
